Code: 570257
Dwyer UV-C112 Ultra-View™ Polysulfone Flowmeter
Normally In Stock
Dwyer UV-C112 - Polysulfone flowmeter, range 5-50 SCFM (70-1400 LPM) air.
Condition: New
Usually ships Same Day or Next Day$486.74
Sale Price
$405.62
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer UV-C112 Ultra-View™ Polysulfone Flowmeter is a reliable and accurate component. It has a wide temperature range of 35 to 212°F (2 to 100°C) and 35 to 130°F (2 to 54°C) for the PVC fitting option. With a pressure limit of 150 psi (10.34 bar) and a process connection of 1" female NPT, it is suitable for use with compatible liquids or gases. The flowmeter features a polysulfone body and fittings, fluoroelastomer O-rings, and a virgin PTFE float for excellent durability. It has an accuracy of ±2% FS and a repeatability of ±1% FS, both at 70 ±2°F (21.1°C) and 14.7 psia. The flowmeter comes with scales ranging from 6" to 7" depending on the model and requires a maximum fitting torque of 22 ft lb.
Specifications
(Instrument-Sensor) Application
Liquid
(Instrument-Sensor) Application
Gas
Component
Flow Meter
(Instrument-Sensor) Temperature Range
35 - 212°F/2 - 100°C
(Instrument-Sensor) Temperature Range
35 - 130°F/2 - 54°C
(Instrument-Sensor) Measurement Accuracy
2.0%
Manufacturer
Dwyer Instruments
(Instrument-Sensor) Type
Ultra-View Polysulfone
Features
Corrosion-resistant polysulfone body ideal for applications where other flowmeters fail saving replacement cost and time
Easy to clean body yields low maintenance costs
Polycarbonate shield protects internal scale increasing product operating life
Low installation costs with optional panel mount polysulfone fittings
