3M 7000006042 - 3M Motor Lead Pigtail Splice 5322, 5-8 kV, 2-1/0 AWG (feeder), 4-1/0 AWG (motor lead)
Normally In Stock
Code: 474282
3M Motor Lead Pigtail Splice 5322, 5-8 kV, 2-1/0 AWG (feeder), 4-1/0 AWG (motor lead) - 7000006042
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$520.54
Sale Price
$433.78
SOLD BY THE CASE (1 Case = 1 Kit)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
3MMotor Lead Splices (Catalog Number 5322) are designed for voltage range of 5 kV to 8 kV. It is suitable for pigtail only splice type and can be used with both non-shielded and shielded pigtail connections. The splice accommodates insulation outside diameter range of 10.9 - 16.5 mm (0.43-0.65 in) and can be used with range feeder cables of 2-1/0 AWG & kcmil. The maximum bolt length is 3/4 in (19.1 mm) and it can accommodate motor leads and feeder leads of up to 1/0 AWG. The lug cover length is adjustable from 8-9 in (203.2-228.6 mm). - 7000006042
Specifications
Manufacturer
3M
Component
Motor Lead Splice
Splice Type
Pigtail Only
