Code: 473575
3M 7000031401 - Scotchlok™ Copper One Hole Long Barrel Lug 31045, up to 35 kV, 4/0 AWG, Purple
Normally In Stock
Scotchlok™ Copper One Hole Long Barrel Lug 31045, up to 35 kV, 4/0 AWG, Purple - 7000031401
Condition: New
CALL FOR LEAD TIMEMUST ORDER A MINIMUM OF $500 FROM 3M FOR PRODUCT TO SHIP
$197.58
Sale Price
$164.65
SOLD BY THE CASE (1 Case = 10 Each)
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Scotchlok™ Compression Lugs are long barrel copper connectors designed for use with copper conductors only. They have a maximum operating voltage of 35 Kilovolt and can accommodate 4/0 AWG conductor sizes. The lug has one hole for a 1/2 inch stud and measures 3.32 inches in overall length (84.4 mm). The purple lug has an outer diameter of 0.68 inches (13.9 mm) and comes in a case quantity of 10. - 7000031401
Specifications
Component
Compression Lug
Material
Copper
Manufacturer
3M
Sub Brand
Scotchlok™
Maximum Conductor Size (Imperial)
4/0 AWG
Overall Length (Imperial)
3.32 In
Color
Purple
Overall Length (Metric)
84.4 mm
Features
Long barrel ensures a secure fit and offers reliable performance
Barrel has colored stripes that help to indicate the wire range
Suitable for indoor and outdoor applications
Made of copper for good conductivity and tin plating for corrosion resistance
Rated for 35 kV applications
UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
