Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 240235
Phoenix Contact 1762631 PCB connector PC 35 HC/ 6-STF-15,00
Normally In Stock
Phoenix Contact 1762631 PCB Plug, Green, rated voltage: 000 V, nom. current: 125 Amp,Number of positions: 6,Number of connections: 6,
Condition: New
Usually ships Same Day or Next Day $77.66
Sale Price
$64.72
MUST BUY IN PACKS OF 25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1762631 The given connector has a nominal cross-section area of 35 mm² and is colored green, with a maximum rated current of 125 A and a voltage rating of 1000 V. It features silver contacts on an Ag surface, uses a socket connection type, includes six potentials, and consists of one row with six positions. The connection method involves screwing with a tension sleeve, utilizing an L-slotted screw head, and has a 15 mm pitch.
Specifications
Connector Color
Green
Connector Amperage
125 Amp
Manufacturer
Phoenix Contact
Number of Connections
6
Number of Positions
6
Component
PCB
Sub Component
PCB Plug
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
Integrated double steel spring provides additional safety in the event of temperature and power fluctuations
Screwable flange for superior mechanical stability
Integrated protective guide prevents incorrect insertion of the conductor underneath the tension sleeve
