Phoenix Contact 1417307 Contact insert module HC-M-DSUB 09-UT-F
Normally In Stock
Code: 237849
Phoenix Contact 1417307 - D-SUB - 9 Positions - Copper Alloy - 28 AWG - Light gray - 1 Amp - 48 V - Screw Connection
Condition: New
Usually ships Same Day or Next Day$42.67
Sale Price
$35.56
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1417307 The contact insert module features nine positions, is a D-SUB connector type, and has a screw socket connection. It operates at 48 volts and 1 ampere, with two different cross-sectional areas of 0.08 mm² and 0.5 mm². Its intended application is for data transmission purposes.
Specifications
Connector Amperage
1 Amp
Connector Color
Light Gray
Connector Material
PC
Connector Material
Copper Alloy
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
9
Sub Component
Contact Insert Module
Connector Voltage
48 Volt
Features
The right connection for your requirements every time with three different series
Compatible connection: housings and contact inserts are mounting and plug-in compatible with solutions from well-known manufacturers
Flexible combination: variable connection technologies for contact inserts and terminal adapters
Customized, compact interface: combine modular contact inserts for signals, data, power, and pneumatics in one connector
Protection against electromagnetic interference: metal housings are EMC-ready due to their conductive surfaces and seals
