Weidmuller 1753740000 Intermediate Plate
Normally In Stock
Code: 198821
Weidmuller 1753740000 - Intermediate Plate - Orange (MUST BUY IN PACKS OF 100)
Condition: New
Usually ships within 4 weeks. Call for ship time.$0.91
Sale Price
$0.76
MUST BUY IN PACKS OF 100
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Weidmuller 1753740000 - Weidmuller offers a comprehensive range of PCB Terminals and Connectors, including the OMNIMATE Signal and OMNIMATE Power series, designed for industrial applications with a focus on signal processing and power electronics. These terminal blocks, plug-in connectors, and panel feedthrough terminal blocks provide efficient and reliable solutions. The OMNIMATE Power series is specifically optimized for high-current applications, supporting currents up to 232 A and voltages up to 1000 V (IEC) or 230 A at 600 V (UL). With a strong emphasis on application-oriented design, these components enable efficient production and ensure reliable performance in a variety of industrial applications. Trust Weidmuller's PCB Terminals and Connectors for high-quality, dependable solutions in signal processing and power electronics.
Specifications
Connector Color
Orange
Connector protection
IP20
Manufacturer
Weidmuller
Component
PCB Terminal
Sub Component
Intermediate Plate
Number of Poles
1 Pole
Features
The maximum voltage is based on the minimum distance.
Intermediate plates increase the creepage and clearance distances between different potentials and permit higher rated voltages or a clear separation, e.g. between mains and low voltages or different protection zones.
The dovetail joint enables easy installation and guarantees a secure fit.
Other characteristics include: Pitch extended by 1.27 or 2.54mm - all other combinations possible Colour coding ensures visual differentiation Different geometries for standard designs.
Incomplete individual assemblies avoided because separate terminal blocks combine to form a single holistic unit.
Ready-assembled on request.
The advantages: efficient processing, increased stability, improved reliability.
