Phoenix Contact 1084564 Assembled PCB connectors CAC-MSTBC1809750/D
Normally In Stock
Code: 154299
Phoenix Contact 1084564 CAC-MSTBC1809750/D Green ,PA,Tin-plated Cu litz wires,Tin-plated Cu litz wires Assembled PCB connectors
Condition: New
Usually ships Same Day or Next Day $192.73
Sale Price
$160.61
MUST BUY IN PACKS OF 25
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1084564 A connector cable with two printed circuit board (PCB) connectors is provided, suitable for connections rated at a maximum current of 12 amps. The cable's length can be customized within the range of 0.1 to 3.0 meters. Two heads are featured on the cable: one contains four individual litz wire contacts made of 16 AWG black PVC cable, and the other features another set of four individual litz wire contacts but with a 14 AWG black PVC cable type.
Specifications
Connector Amperage
12 Amp
Connector Color
Green
Connector Material
PA
Connector Material
Tin-Plated Cu Litz Wires
Manufacturer
Phoenix Contact
Number of Positions
4
Component
PCB
Sub Component
Assembled PCB Connector
Connector Voltage
300 Volt
Connector Voltage
1500 Volt
Connector Voltage
3000 Volt
Features
Crimping connection: vibration- and temperature-resistant assembly
Screwable flange for superior mechanical stability
Simple and safe: 100% electrically tested and assembled ready for use
Approval in accordance with UL standard “Wiring Harness Traceability Program”
