Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Code: 153339
Phoenix Contact 1832772 DIN rail connector MCVK 1,5/ 6-G-3,81
Normally In Stock
Phoenix Contact 1832772 MCVK 1,5/ 6-G-3,81 ,Copper Alloy,PA,I Feed-through header
Condition: New
Usually ships Same Day or Next Day $22.72
Sale Price
$18.93
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1832772 The DIN rail connector has a nominal cross-sectional area of 1.5 mm², is green in color, and can carry up to 8 A of current at a rated voltage of 160 V. It features a tin contact surface with pin-style connections, accommodating six potentials across one row with 6 connections available. The product falls within the MCVK 1,5/..-G range, has a pitch of 3.81 mm, and is secured via screw connections with a tension sleeve.
Specifications
Connector Amperage
8 Amp
Connector Voltage
2.5 Kv
Connector Voltage
2.95 Kv
Connector Voltage
1.39 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Component
DIN Rail Connector
Manufacturer
Phoenix Contact
Number of Connections
6
Number of Positions
6
Connector Voltage
160 Volt
Connector Voltage
320 Volt
Features
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Direct plug-in block for DIN rail mounting
For mounting on a DIN rail NS 15
Well-known connection principle allows worldwide use
