Phoenix Contact 1884775 Contact insert VC-D4-BU65-PE-R
Normally In Stock
Code: 151947
Phoenix Contact 1884775 - Contact insert - VARIOCON - 65 Positions - CuZn - 22 AWG - 10 Amp - Crimp Connection
Condition: New
Usually ships Same Day or Next Day $28.66
Sale Price
$23.88
MUST BUY IN PACKS OF 10
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1884775 The contact insert has a design designated as VC4 and is part of the VARIOCON range, with 65 available positions. It features varying conductor cross-sections between 0.14 mm2 and 1.5 mm2, operates at a rated voltage of 250 volts and can handle a maximum current of 10 A. Crimp connection method is used along with socket contact type, and connectors should only be connected or disconnected when the system is under no load.
Specifications
Connector Amperage
10 Amp
Connector Size
VC4
Connector Material
Cuzn
Component
Contact Insert
Manufacturer
Phoenix Contact
Number of Positions
65
Features
Pin and socket contacts can be used on both the plug and device sides
Contact carriers have two further capacitive PE contacts
The connection data of 250 V/10 A corresponds to that of the HEAVYCON DD series
Contact types meet the requirements of IEC 60352/DIN EN 60352
