Phoenix Contact 1766161 A printed circuit board terminal has a nominal current rating of 22 A and is rated for a voltage of 400 V. The terminal's cross-sectional area is 2.5 mm² and features 58 potentials, arranged in a 2x29 grid layout with a pitch of 5.08 mm. Connections are made using a screw method with a tension sleeve, featuring an L-slotted screw head. This terminal is designed for wave soldering mounting and has a linear pinning arrangement, where each potential uses one solder pin measuring 5 mm in length. The terminal comes packaged in cardboard and is identified by the product code MK3DSMH 3.
