Dwyer RMA-44 Water and Liquid Flow Meter
Normally In Stock
Code: 14738
Dwyer RMA-44 Water and Liquid Flow Meter (Rate-Master) 2" Scale with No Valve,range 4-34 GPH water (.001-.01 GPM)(150-1818 CCM). For compatible gases and liquids. Temperature limit 130 F. Pressure Limit 100 psi (6.9 bar). Accuracy 4%,Process Connection 1/8" Weight 4 oz. Wetted Materials: body is polycarbonate,O-ring is Neoprene & Buna-N,Metal Parts are No except for optional No valve,Float is No,black glass,aluminum,K monel,tungsten carbide.
Condition: New
Usually ships Same Day or Next Day$69.50
Sale Price
$57.92
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer RMA-44 Water and Liquid Flow Meter (Rate-Master) 2" Scale with No Valve,range 4-34 GPH water (.001-.01 GPM)(150-1818 CCM). For compatible gases and liquids. Temperature limit 130 F. Pressure Limit 100 psi (6.9 bar). Accuracy 4%,Process Connection 1/8" Weight 4 oz. Wetted Materials: body is polycarbonate,O-ring is Neoprene & Buna-N,Metal Parts are No except for optional No valve,Float is No,black glass,aluminum,K monel,tungsten carbide.
Specifications
Component
Water And Liquid Flow Meter
(Instrument-Sensor) Size
0.125"
(Instrument-Sensor) Type
Variable Area
(Instrument-Sensor) Output Signal Type
2" Scale
(Instrument-Sensor) Temperature Range
103 F
(Instrument-Sensor) Span
2573 CCM
(Instrument-Sensor) Span
300 CCM -
(Instrument-Sensor) Span
.066 GPM - .566 GPM
(Instrument-Sensor) Span
4 GPH - 34 GPH
(Instrument-Sensor) Type of Operator
No Valve
(Instrument-Sensor) Measurement Accuracy
4.0%
Manufacturer
Dwyer Instruments
Features
Eliminate the need for troublesome conversions with direct reading scales
Reduce installation damage and cost due to stainless steel backbone that absorbs piping torque
Long operation life with durable, shatter-proof polycarbonate body
High repeatability enabled by precision injection molding around a precision tapered pin
Increased reading accuracy with special integral flow guides that stabilize float movement
Save time with instantaneous flow reading with the presence of scale graduations on both side of the indicating tube
