Phoenix Contact 1828401 The PCB connector features a nominal cross-sectional area of 1.5 mm², has a green color and is designed to handle a maximum current of 8 A with a rated voltage of 160 V (III/2). The contact surface is made of tin (Sn) and uses a socket connection type, offering eight potentials across one row of eight positions. The connector utilizes screw connections with tension sleeves, featuring L Slotted screw heads and allows for conductor/PCB connections at a 90 ° angle, utilizing the COMBICON MC 1.5 plug-in system with screw locking mechanisms for secure mounting via its screw flange, packaged in cardboard.
