Phoenix Contact 1848985 PCB connector LPC 1,5/11-ST-3,81
Normally In Stock
Code: 145433
Phoenix Contact 1848985 LPC 1,5/11-ST-3,81 ,Copper Alloy,PA,I,PA GF PCB connector
Condition: New
Usually ships Same Day or Next Day$15.29
Sale Price
$12.74
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1848985 The PCB connector features a nominal cross section of 1.5 mm2 and has a green color, with a rated current of 8 A and a voltage rating of up to 160 V. The contact surface is coated with tin, and the connection method uses a Lever Push-in design, with a pitch of 3.81 mm. This connector has 11 positions and is part of the LPC 1,5/..-ST product range, while also being designed for use in the COMBICON MC 1,5 plug-in system, which requires no locking clip or mounting method, and is packaged in cardboard packaging.
Specifications
Connector Amperage
8 Amp
Connector Voltage
2.5 Kv
Connector Material
I
Connector Material
PA
Connector Material
PA GF
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Number of Positions
11
Component
PCB
Sub Component
PCB Plug
Connector Voltage
160 Volt
Connector Voltage
320 Volt
Features
Tool-free lever principle enables time-saving connection and release of conductors with/without ferrules
Clear lever positions provide reliable feedback on opened or closed clamping spaces
Time-saving push-in connection when lever is closed
Quick and convenient testing using integrated test option
