Phoenix Contact 1754562 PCB connector MSTB 2,5/ 8-ST
Normally In Stock
Code: 144963
Phoenix Contact 1754562 MSTB 2,5/ 8-ST ,Copper Alloy,PA,I Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $9.11
Sale Price
$7.59
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1754562 The PCB connector is a green color with a nominal cross-sectional area of 2.5mm² and a maximum current rating of 12A at a rated voltage of 320V (III/2). It features a socket contact surface made of tin and has 8 positions, connected by screw connection with tension sleeve, where the L Slotted screw head secures the conductor to the PCB in a 0° direction. The connector also includes a locking clip for secure plugging and mounting systems, packaged in cardboard without any additional mounting or packaging requirements.
Specifications
Connector Amperage
12 Amp
Connector Voltage
4 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Connector Voltage
.21 Kv
Number of Connections
8
Number of Positions
8
Component
PCB
Sub Component
PCB Plug
Connector Voltage
320 Volt
Connector Voltage
250 Volt
Connector Voltage
630 Volt
Features
Well-known connection principle allows worldwide use
Low temperature rise, thanks to maximum contact force
Allows connection of two conductors
