Phoenix Contact 1765962 The PCB connector has a nominal cross section of 2.5mm² and is colored green, with a maximum current rating of 12A and a rated voltage of 320V. The contact surface material is Sn, with a socket connection type and 21 potentials. The dimensions include one row and 21 positions for connections, which are secured using screw connections with tension sleeves and have an L slotted screw head. The conductor and PCB connection direction is perpendicular to the contact surface at 0° degrees, and there is no locking clip; instead, it's a plug-in system called COMBICON MSTB 2.5, which doesn't require mounting as the product comes packed in cardboard.
