Phoenix Contact 1011115 PCB header MC 1,5/ 8-G-3,5 P20 THRR44
Normally In Stock
Code: 141098
Phoenix Contact 1011115 MC 1,5/ 8-G-3,5 P20 THRR44 ,Copper Alloy,LCP,IIIa Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day$520.39
Sale Price
$433.66
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1011115 PCB headers feature a nominal cross-sectional area of 1.5mm2, with a black color and a maximum current rating of 8A, supported by a voltage rating of 160V. The headers have a Sn contact surface, use pin connections, consist of 8 potentials arranged in a linear layout, and are soldered using either wave or THR soldering methods, with 2mm-long solder pins per potential.
Specifications
Connector Amperage
8 Amp
Connector Material
Iiia
Connector Material
LCP
Connector Voltage
2.5 Kv
Connector Voltage
2.95 Kv
Connector Voltage
1.39 Kv
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Number of Connections
8
Number of Positions
8
Component
PCB
Sub Component
PCB Header
Connector Voltage
160 Volt
Connector Voltage
250 Volt
Features
Designed for integration into the SMT soldering process
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
