Phoenix Contact 2817741 Type 2 surge protection base element VAL-MS BE
Normally In Stock
Code: 1092
VAL-MS BE Phoenix Contact VAL-MS BE Base element for type 2 arresters of the VALVETRAB MS series of products. Design: 1-channel
Condition: New
Usually ships Same Day or Next Day$42.96
Sale Price
$35.80
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2817741 The base element for type 2 arresters in the VALVETRAB MS product series is a one-channel design, providing a straightforward and efficient configuration for these types of protection devices.
Specifications
Surge Protector Mount
Din Rail Mount
Fault Warning
Optical
Max Discharge Capacity
20 A
Combined Surge
6 Kv
Manufacturer
Phoenix Contact
Component
Accessories
Connection Method
Screw Connection
Surge Protector Type
Replacement Plug
Maximum Continous Voltage
150 Volt
Nominal Discharge Current
5 Ka
Sub Component
Base Element
Features
Wide range of applications due to various nominal voltages
Rapid installation with bridges, thanks to industry-standard overall width of 1 HP
Easy testing and insulation measurement, thanks to pluggable protection modules
Quality proven millions of times over in the widest range of applications
High degree of modularity provides individual solutions for every application
Downloads
Phoenix 2817741 CAD data International.dxfPhoenix 2817741 CAD data International.pdfPhoenix 2817741 CAD data International.stpPhoenix 2817741 CAD Drawing.zipPhoenix 2817741 Flyer English.pdfPhoenix 2817741 Manufacturers declaration English.pdfPhoenix 2817741 Manufacturers declaration International.pdfPhoenix 2817741 Package Slip International.pdfPhoenix 2817741 Product Information English.pdfPhoenix 2817741 Software International.zipPhoenix 2817741 Spec Sheet.pdfPhoenix 2817741 Surge Protection English.pdfPhoenix 2817741 Tender Text English.zipPhoenix 2817741 User Manual.pdfPhoenix 2817741 Various International.pdf
