Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Schneider Electric 9001KYK25 - 30Mm push button, Type K, control station, two push buttons, 6A inductive at 120VAC, marked UP and DOWN, NEMA 4, 13
Normally In Stock
Code: 659314
Schneider Electric 9001KYK25 - 30Mm push button, Type K, control station, two push buttons, 6A inductive at 120VAC, marked UP and DOWN, NEMA 4, 13
Condition: New
Usually ships Same Day or Next Day*NON-CANCELLABLE, NON-RETURNABLE*
$403.66
Sale Price
$336.38
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric 9001KYK25 - 30Mm push button, Type K, control station, two push buttons, 6A inductive at 120VAC, marked UP and DOWN, NEMA 4, 13
Specifications
Manufacturer
Schneider Electric
Features
The 9001K push button line has a large variety of operators and accessories for heavy industry applications
These operators are used in the petrochemical, metallurgy, mining, oil and gas, wastewater treatment and automotive manufacturing industries and more
This assembled control station has a gray die cast zinc enclosure (9001KY2) with two operators
Control station has a black full guard momentary push button (9001KR1B) in the top hole
The push button has a contact block with 1 normally open and 1 normally closed contact (9001KA1)
The operator has a black legend plate that is marked UP (9001KN211)
Control station has a black full guard momentary push button (9001KR1B) in the bottom hole
The push button has a contact block with 1 normally open and 1 normally closed contact (9001KA1)
The operator has a black legend plate that is marked DOWN (9001KN210)
The enclosure has one 0.75 inch conduit opening with 14 NPT thread
Enclosure is 5.75 inches tall, 3.62 inches wide and 4.16 inches deep
This enclosure is rated for NEMA 1, 3, 4, 6, 12 and 13 environments
The control station is UL Listed and CSA certified
\A comprehensive range of illuminated pushbuttons, pilot lights, emergency stop buttons, selector switches, joystick controllers and accessories to fit your needs.\,\The modular range of Ø 30mm metal control and signaling provides robust and reliable solutions for a wide range of heavy industry applications.\
