Schneider Electric 170ADI35000 - discrete input module Modicon Momentum - 32 Input 24 V DC
Normally In Stock
Code: 658987
Schneider Electric 170ADI35000 - discrete input module Modicon Momentum - 32 Input 24 V DC
Condition: New
Usually ships Same Day or Next Day$536.63
Sale Price
$447.19
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Schneider Electric 170ADI35000 - discrete input module Modicon Momentum - 32 Input 24 V DC
Specifications
Manufacturer
Schneider Electric
Features
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture
This discrete input base DC module offers 2 groups of 16 inputs, conforming to IEC 1131-2 type 1 with positive discrete input logic
It is a module with discrete input voltage of 24V DC
There is an isolation between channels and ground at 500V AC
It features 32 LEDs for channel status signaling
Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height)
It weighs 0.2kg
The main application of this module is infrastructures and energy, material handling, simple machine control
This product is certified by CE, CSA and UL
It is suitable for wall mount
Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications
System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
