Phoenix Contact 1534575 Device connector rear mounting SACCBP-M12FSB-5CON-M16/5,0-900
Normally In Stock
Code: 173679
Phoenix Contact 1534575 - Device connector, rear mounting - 6 Positions - CuZn - IP67 - Cable Connection - SPEEDCON Locking - M12
Condition: New
Usually ships Same Day or Next Day$109.18
Sale Price
$90.98
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1534575 This device connector features a rear mounting design with an INTERBUS connection at 16 Mbps, available in a 5-position, PUR halogen-free housing that is green RAL 6017 and shielded. The M12-SPEEDCON socket has a coding of B and is mounted on the free end of the cable via M16 x 1.5, with a cable length of 5 meters. Due to an ongoing transition to lead-free alternatives in line with RoHS II, this item can be replaced with a similar lead-free version upon request, which contains less than 0.1% lead (6c classification).
Specifications
Connector Material
PA 6.6
Connector Material
Cuzn
Connector protection
IP67
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
6
Sub Component
Device Connector-Rear Mounting
Features
Preassembled with cables in various standard lengths for immediate use
Customer-specific assemblies and cable lengths can be supplied
Sealed on the cable side for optimum tightness of seal
Cable designs for all common networks and fieldbuses
For high transmission safety: shield connection to the housing with optional EMC nut
Code: 173679
Phoenix Contact 1534575 Device connector rear mounting SACCBP-M12FSB-5CON-M16/5,0-900
