Phoenix Contact 1534478 Device connector rear mounting SACCBP-M12FS-5CON-M16/1,0-920
Normally In Stock
Code: 173675
Phoenix Contact 1534478 - Device connector, rear mounting - 4 Positions - CuZn - IP67 - Cable Connection - M12
Condition: New
Usually ships Same Day or Next Day$81.88
Sale Price
$68.23
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 1534478 The device connector features rear mounting capabilities with a CANopen and DeviceNet coding scheme, utilizing a 5-position socket with a shielded and straight design made from a halogen-free, purple-colored (RAL 4001) M12 material on one end and a male M16 x 1.5 thread at the other, accommodating connections over a length of approximately 1 meter.
Specifications
Connector Material
PA 6.6
Connector Material
Cuzn
Connector protection
IP67
Component
Connector
Manufacturer
Phoenix Contact
Number of Positions
4
Sub Component
Device Connector-Rear Mounting
Features
Preassembled with cables in various standard lengths for immediate use
Customer-specific assemblies and cable lengths can be supplied
Sealed on the cable side for optimum tightness of seal
Cable designs for all common networks and fieldbuses
For high transmission safety: shield connection to the housing with optional EMC nut
