Phoenix Contact 1748480 PCB connector FMC 1,5/15-STF-3,81
Normally In Stock
Code: 144763
Phoenix Contact 1748480 FMC 1,5/15-STF-3,81 ,Copper Alloy,PA,I,PBT Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $14.21
Sale Price
$11.84
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1748480 This connector has a nominal cross-sectional area of 1.5mm2, is colored green, and can handle a nominal current of 8A with a rated voltage of 160V. It features a contact surface made of tin, uses a socket connection type, and includes 15 potential connections arranged in one row across 15 positions on the PCB. The connector is part of the FMC 1,5/..-STF product range, has a pitch of 3.81mm, and utilizes push-in spring connections with no conductor or PCB connection orientation specified.
Specifications
Connector Amperage
8 Amp
Connector Material
PBT
Connector Voltage
2.5 Kv
Connector Voltage
2.95 Kv
Connector Voltage
1.39 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Number of Connections
15
Number of Positions
15
Component
PCB
Sub Component
PCB Plug
Connector Voltage
160 Volt
Connector Voltage
320 Volt
Features
Time saving push-in connection, tools not required
Defined contact force ensures that contact remains stable over the long term
Intuitive operation due to color-coded actuating push button
Operation and conductor connection from one direction enable integration into front of device
Screwable flange for superior mechanical stability
