Phoenix Contact 1962613 PCB connector TFKC 2,5/ 3-ST-5,08
Normally In Stock
Code: 144488
Phoenix Contact 1962613 TFKC 2,5/ 3-ST-5,08 ,Copper Alloy,PA,I,PBT Printed-circuit board connector
Condition: New
Usually ships Same Day or Next Day $8.21
Sale Price
$6.84
MUST BUY IN PACKS OF 50
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1962613 The PCB TWIN plug has a nominal cross-sectional area of 2.5mm² and is identified by its green color, with a rated voltage of 320V at 12A nominal current. It features a Sn contact surface, socket connection type, and includes three potentials across one row of positions. The six connections are secured via push-in spring connections without locking clips, and the plug uses the COMBICON MSTB 2.5 system with no external mounting required, packaged in cardboard.
Specifications
Connector Amperage
12 Amp
Connector Material
PBT
Connector Voltage
4 Kv
Connector Material
I
Connector Material
PA
Connector Material
Copper Alloy
Manufacturer
Phoenix Contact
Connector Voltage
.21 Kv
Number of Positions
3
Number of Connections
6
Component
PCB
Sub Component
PCB Plug
Connector Voltage
320 Volt
Connector Voltage
630 Volt
Features
Time saving push-in connection, tools not required
Potentials can be easily looped through – ideal for BUS applications
Intuitive operation due to color-coded actuating push button
Can be combined with the MSTB 2,5 range
Quick and convenient testing using integrated test option
