Phoenix Contact 1815125 PCB header PTSM 0,5/ 2-HHI0-2,5-SMD R24
Normally In Stock
Code: 140551
Phoenix Contact 1815125 PTSM 0,5/ 2-HHI0-2,5-SMD R24 Feed-through header
Condition: New
Usually ships Same Day or Next Day $1.03
Sale Price
$0.86
MUST BUY IN PACKS OF 500
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 1815125 PCB headers with a nominal cross-section of 0.5mm2 have a black color and are rated for a maximum current of 6A at an operating voltage of 160V. They feature soldering for SMD mounting with a linear pad geometry, featuring two rows and two positions per connection, each requiring one solder pin.
Specifications
Manufacturer
Phoenix Contact
Component
PCB
Sub Component
PCB Header
Features
Designed for integration into the SMT soldering process
Supplied in tape-on-reel packing according to IEC 60286-3 for automated mounting
Inverted header with socket contacts for touch-proof device outputs or PCB/PCB connections
Additional solder anchors reduce the mechanical strain on the soldering spots
