Nidec Motors
Nidec Motors is a well-known motor corporation that functions globally and concentrates on high-performance electric motors for the industrial, commercial, and residential sectors. The company, which is a part of Nidec Corporation, concentrates on advanced motor technology that aims to boost efficiency, reliability, and sustainability across an array of sectors, including oil and gas. Their expertise covers pump motors, appliance motors, and a range of industrial systems, where they claim to deliver superior performance in demanding applications, like water treatment and air-conditioning systems. The company states that a commitment to excellence ensures that the motor controls they produce and their energy-efficient solutions operate at "optimal levels."
The company plays a vital part in making the motors that serve the nation's most important industries, among them the key sectors of commercial infrastructure, transportation, and electronics. Their pump motors are used coast to coast in water treatment plants, and they ensure the flow of reliable water through the systems. In industrial applications, Nidec's motor controls ensure that energy is used efficiently, and they optimize the use of what would otherwise be prime power components. If you have an application that uses electricity to do the work of a motor, you want a Nidec motor.
Products
Sort By:
Nidec BR12S2AC3 - TEFC, 0.5 HP, 3 Phase, 460 Volt
$1768.20
$1979.90
Nidec BR12S2AC3 - Definite Purpose Totally Enclosed Fan Cooled (TEFC) Motor FCR Series Brakemotor is designed for applications requiring manual release, brake torque adjustments, and high cycling, such as bulk material handling equipment, conveyors, cranes, and hoists. It features Class F insulation, a pressure die-cast aluminum alloy frame, and oversized non-regreasable ball bearings. The motor has a high braking torque with a 180-volt DC brake coil and an included rectifier. It operates with a 1.15 service factor at 60 Hertz in 40°C ambient conditions for continuous duty. Additional features include an easily adjustable air gap and compatibility with multiple voltage settings: 60 Hertz at 208-230/460 volts and 50 Hertz at 380 volts with a 1.0 service factor.
Nidec BR12S2A3 - TEFC, 0.5 HP, 3 Phase, 460 Volt
$1598.70
$1790.10
Nidec BR12S2A3 - Definite Purpose Totally Enclosed Fan Cooled (TEFC) Motor FCR Series Brakemotor is designed for applications requiring manual release, brake torque adjustments, and high cycling, such as bulk material handling equipment, conveyors, cranes, and hoists. It features Class F insulation, a pressure die-cast aluminum alloy frame, and oversized non-regreasable ball bearings. The motor has a high braking torque with a 180-volt DC brake coil and an included rectifier. It operates with a 1.15 service factor at 60 Hertz in 40°C ambient conditions for continuous duty. Additional features include an easily adjustable air gap and compatibility with multiple voltage settings: 60 Hertz at 208-230/460 volts and 50 Hertz at 380 volts with a 1.0 service factor.
Nidec JS100UPR - ODP, 1 HP, 1 Phase, 230 Volt
$321.10
$360.10
Nidec JS100UPR - Special Application Single Phase, Open Drip Proof (ODP) Jet Pump motor, available in square flange and C-face configurations, is designed for applications such as jet pumps, booster pumps, centrifugal pumps, and lawn sprinkler pumps. Key features include a 303 stainless steel shaft with specific threading (7/16-20 UNF2A for C-face and 1/2-20 UNC-2A for square flange), ball bearings with a locked drive end bearing, and continuous duty operation at 60 Hz. The motor also has an EZ-Access motor cover, operates in a 40°C ambient environment, and includes an automatic reset thermal overload protector. It features a round frame without a base, NEMA® 56C C-face or square flange mounting, and power leads for proper connection to a pressure switch. Additionally, it has a voltage selector switch for models ending in "-2V" and "UPR".
Nidec 481872 - ODP, 1.5 HP, 3 Phase, 440 Volt
$373.53
$406.90
Nidec 481872 - Blower/Fan Motor, 1.5 HP, 440 Volt, 1800 RPM, 60 Hz, 50 Hz
Nidec BR34S2ACR3 - TEFC, 0.75 HP, 3 Phase, 460 Volt
$1727.57
$1934.40
Nidec BR34S2ACR3 - Definite Purpose Totally Enclosed Fan Cooled (TEFC) Motor FCR Series Brakemotor is designed for applications requiring manual release, brake torque adjustments, and high cycling, such as bulk material handling equipment, conveyors, cranes, and hoists. It features Class F insulation, a pressure die-cast aluminum alloy frame, and oversized non-regreasable ball bearings. The motor has a high braking torque with a 180-volt DC brake coil and an included rectifier. It operates with a 1.15 service factor at 60 Hertz in 40°C ambient conditions for continuous duty. Additional features include an easily adjustable air gap and compatibility with multiple voltage settings: 60 Hertz at 208-230/460 volts and 50 Hertz at 380 volts with a 1.0 service factor.
Nidec NT32P1BE - TEFC, 1.5 HP, 3 Phase, 460 Volt
$1598.51
$1877.20
Nidec NT32P1BE - Vertical Solid Shaft Motor, 1.5 HP, 460 Volt, 3600 RPM, 60 Hz, Rolled Steel
Nidec NT1P2BE - TEFC, 1 HP, 3 Phase, 460 Volt
$1257.55
$1476.80
Nidec NT1P2BE - Vertical Solid Shaft Motor, 1 HP, 460 Volt, 1800 RPM, 60 Hz, Rolled Steel
Nidec NT32P2BE - TEFC, 1.5 HP, 3 Phase, 460 Volt
$1452.38
$1705.60
Nidec NT32P2BE - Vertical Solid Shaft Motor, 1.5 HP, 460 Volt, 1800 RPM, 60 Hz, Rolled Steel
Nidec NT2P1BE - TEFC, 2 HP, 3 Phase, 460 Volt
$1689.28
$1983.80
Nidec NT2P1BE - Vertical Solid Shaft Motor, 2 HP, 460 Volt, 3600 RPM, 60 Hz, Rolled Steel
Nidec NT1P3BE - TEFC, 1 HP, 3 Phase, 460 Volt
$1704.78
$2002.00
Nidec NT1P3BE - Vertical Solid Shaft Motor, 1 HP, 460 Volt, 1200 RPM, 60 Hz, Rolled Steel
Nidec WDS3P1A14C - TEFC, 3 HP, 3 Phase, 460 Volt
$1982.02
$2982.20
Nidec WDS3P1A14C - All Stainless Steel Washdown Three Phase motor, designed for applications in food processing, canning, meat packing, bakeries, dairies, and pharmaceutical manufacturing, features a robust construction entirely made of stainless steel. With a 40°C ambient rating and NEMA® Design B compliance, it ensures reliability in diverse environments. Its INVERTER GRADE® insulation system meets NEMA® MG-1 Part 31 standards, while a 303 stainless steel shaft enhances durability. The motor incorporates multiple stainless steel T-type drains, is Totally Enclosed Fan Cooled (TEFC) in most cases, and includes rust inhibitor on the rotor. BISSC® certification ensures compliance with industry sanitation standards, while VBX® Bearing Isolators by Inpro/Seal and double-sealed ball bearings enhance longevity. Other features include a laser-etched oversized nameplate, RTV-sealed lead exit holes, moisture-resistant gasketed conduit box with NPT lead holes, and easy-to-read connection leads, ensuring ease of maintenance and sanitation in demanding environments.
Nidec 8P1P3C - TEFC, 1 HP, 3 Phase, 460 Volt
$1037.15
$1392.30
Nidec 8P1P3C - General Purpose Three Phase, Totally Enclosed Fan Cooled (TEFC) 841 PLUS® motor is designed for constant speed and inverter duty applications in various industries, including petro-chemical, pulp & paper, automotive, mining, and waste treatment. It features an INVERTER GRADE® insulation system that meets NEMA® MG-1 Part 31 standards, with Class F insulation and Class B rise at full load. The motor boasts an all cast iron construction with an IP55 enclosure, corrosion-resistant paint, and VBXX® bearing isolators for IP66 bearing protection. Additional features include regreasable open bearings, epoxy-coated rotor, and a 1.15 service factor on sine wave and 1.0 on inverter power. It supports 20:1 variable torque and 5:1 constant torque on inverter power, precision balance, and has a 5-year warranty. The motor also meets or exceeds IEEE 841 Standard 2009 and includes various conversion kits and provisions for enhanced versatility and durability.
