Mersen C301302 Fuse - Class aR, 650 Volts, 1800 Amp

Mersen C301302 - These 1250/1300V Protistor® fuse-links provide maximum flexibility in equipment design and ultimate protection for today's power conversion equipment. These aR ultra-fast acting square body fuse-links are available in different body sizes, each size having multiple worldwide acceptable mounting styles.The Protistor® have been engineered to provide state-of-the-art protection for semiconductors: diodes, thyristors and IGBT devices. Fuses are assembled with die-cut elements embedded in solidified sand, which helps control arcing characteristics for a lower I²t and high interrupting rating level. All contact surfaces are silver plated and all hardware is non-magnetic.All fuse-links can be equipped with a low voltage trip-indicator which can operate a field mountable microswitch.

Specifications
Manufacturer	Mersen
Fuse Amperage Rating	1800 Amp
Component	Fuse
Fuse Type (UL)	Class aR
Mounting	Bolted
Connection/Terminal Material	Silver-Plated Brass
Body/Insulating Material	Ceramic
Indication System Type	Striker
Series	Protistor®
Connection/Terminal Type	End Contact with Threaded Holes
Fuse Voltage Rating	650 Volts
