PT-IQ-3-PB-P Phoenix Contact 2800783 Replacement plug Surge protection plug
PT-IQ-3-PB-P Phoenix 2800783 Replacement plug 5 VDC pluggable Surge protection plug Surge Protection
Normally In Stock! Order now!
Condition: New
Usually ships within 7-14 days. Call for ship time.
Price: $218.75
Sale Price:
$182.00
Surge protection plug with integrated multi-stage status indicator on the module for three signal wires. For HF applications. Nominal voltage: 5 VDC
| Specifications | |
| Fault Warning | Optical |
| Fault Warning | multi-stage |
| Direction of Action | Line-Line |
| Direction of Action | Line-Signal Ground-Shield |
| Direction of Action | optional Signal Ground-Shield-Earth Ground |
| Manufacturer | Phoenix Contact |
| Connection Method | Screw connection |
| Surge Protector Line Voltage | 5 Volt |
| Surge Protector Type | Replacement plug |
| Maximum Continous Voltage | 30 Volt |
- Maximum ease of maintenance, thanks to the 2-piece design
- Integration of the status message into the system controller via group remote signaling
- The signal is not influenced during maintenance work, thanks to the impedance-neutral insertion and removal of protective plugs
- Predictive monitoring with 3-stage LED display
- Maximum protection for MCR applications with high discharge capacity
