PT-IQ-2X2-EX-24DC-P Phoenix Contact 2801515 Replacement plug Surge protection plug
PT-IQ-2X2-EX-24DC-P Phoenix 2801515 Replacement plug 24 VDC Surge protection plug Surge Protection
Normally In Stock! Order now!
Condition: New
Usually ships within 7-14 days. Call for ship time.
Price: $401.25
Sale Price:
$333.84
Surge protection plug with integrated multi-stage status indicator on the module for two 2-wire floating Ex-i signal circuits. Nominal voltage: 24 VDC
| Specifications | |
| Max Discharge Capacity | 80 A |
| Arrester Class according to IEC | II |
| Arrester Class according to IEC | T2 |
| Fault Warning | Remote indication contact |
| Manufacturer | Phoenix Contact |
| Connection Method | Screw connection |
| Surge Protector Line Voltage | 24 Volt |
| Surge Protector Type | Base element |
| Maximum Continous Voltage | 600 Volt |
- Maximum ease of maintenance, thanks to the 2-piece design
- Integration of the status message into the system controller via group remote signaling
- The signal is not influenced during maintenance work, thanks to the impedance-neutral insertion and removal of protective plugs
- Predictive monitoring with 3-stage LED display
- Maximum protection for MCR applications with high discharge capacity
Customer Reviews
0.0
All Reviews
Phoenix 2801515 CAD data International.dxf
Phoenix 2801515 CAD data International.pdf
Phoenix 2801515 CAD data International.stp
Phoenix 2801515 Certification English.pdf
Phoenix 2801515 Certification International.pdf
Phoenix 2801515 Flyer English.pdf
Phoenix 2801515 Flyer English-2.pdf
Phoenix 2801515 Manufacturers declaration English.pdf
Phoenix 2801515 Manufacturers declaration International.pdf
Phoenix 2801515 Package Slip International.pdf
Phoenix 2801515 Software International.zip
Phoenix 2801515 Surge Protection English.pdf
Phoenix 2801515 Tender Text English.zip
