Mersen MPDB68312 Power Distribution Block, 1000 Volts, 760 Amp

Mersen MPDB68312 - The Next Generation Power Distribution Block (PDB). Mersen power distribution blocks provide a safe and easy method of splicing cables, splitting primary power into secondary circuits and fulfilling requirements for fixed junction tap-off points. All blocks are UL and CSA approved while meeting spacing requirements for feeder and branch circuits in conjunction with UL508A and the National Electrical Code®. PDB options include single or dual conductor primary inputs and up to 30 secondary outputs. Specialty blocks are available allowing for up to 7 primary inputs. The MPDB series is offered in three size categories: miniature (MPDB62 and MPDB63 series), intermediate (MPDB66 and MPDB67 series), and large (MPDB68 and MPDB69 series), in both aluminum and copper.

Specifications
Fuse Voltage Rating	1000 Volts
Component	Power Distribution Block
Manufacturer	Mersen
Fuse Amperage Rating	760 Amp
Connection/Terminal Material	Tin-Plated Copper
Mounting	Screw
Number of Poles	2 Pole
Body/Insulating Material	Glass Filled Polycarbonate
Connection/Terminal Type	Box
