Schneider Electric METSEPM5563 PM5563 Meter, 2 ethernet, up to 63th H, 1,1M 4DI/2DO 52 alarms, DIN mounted

Schneider METSEPM5563 Power meter up to the 63rd harmonic Without display 128 samples/cycle Modbus RTU and ASCII 9.6, 19.2 and 38.4 kbauds even/odd or none - 2 wires 2500 V, JBUS, Modbus TCP/IP 10/100 Mbit/s 2500 V, Ethernet Modbus TCP/IP daisy chain, BACnet IP CE IEC 61010-1, CU

Normally In Stock! Order now!

Condition: New

Normally Stocked

Price: $3968.24

Sale Price: $2943.49

Add to Job Add to Favorites Add to Quick Quote

PM5563 Meter, 2 ethernet, up to 63th H, 1,1M 4DI/2DO 52 alarms, DIN mounted

Specifications
Monitoring Approval	CE IEC 61010-1
Monitoring Approval	CULus UL 61010-1
Monitoring Approval	BTL
Monitoring Approval	EN 50470-3
Monitoring Approval	EN 50470-1
Monitoring Approval	IEC 62053-22
Monitoring Approval	IEC 60529
Monitoring Approval	UL 61010-1
Monitoring Approval	IEC 62053-24
Monitoring Approval	IEC 61557-12
Monitoring Approval	ANSI C12.20
Monitoring Interface	JBUS
Monitoring Interface	BACnet IP
Monitoring Interface	Without display
Monitoring Primary Rated Current	1 Amp
Monitoring Primary Rated Current	5 Amp
Monitoring Accuracy Class	Class 0.2S
Monitoring Interface	Modbus RTU and ASCII
Monitoring Interface	Modbus TCP/IP
Manufacturer	Schneider Electric
Monitoring Input Current Range	5-10000 mAmp
Monitoring Measuring Range	128 samples/cycle
Monitoring Supply Voltage	125-250 VDC
Monitoring Supply Voltage	100-480 VAC
Component	Power Meter
