Phoenix Contact 2811569 Signal conditioner MACX MCR-UI-UI-UP-SP-NC
Normally In Stock
Code: 72331
MACX MCR-UI-UI-UP-SP-NC MACX MCR-UI-UI-UP-SP-NC Phoenix Contact 2811569 CE Signal conditioner
Condition: New
Usually ships Same Day or Next Day$653.15
Sale Price
$544.29
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2811569 The isolating amplifier features safe electrical isolation and a versatile power supply range of 24V to 230V AC/DC. Additionally, the device boasts over 1600 possible signal conversion settings, which can be adjusted using DIP switches on the front panel. The standard configuration includes input ranges of 0-10V and output currents up to 20mA, connected via spring-cage terminals, and is rated as SIL (Safety Integrity Level) compliant.
Specifications
Manufacturer
Phoenix Contact
Component
Signal Conditioner
Conditioner Output Signal Range
0 Ma - 20 Ma
Conditioner Output Signal Range
4 Ma - 20 Ma
Conditioner Output Signal Type
Current
Conditioner Input Signal Type
Current
Conditioner Number of Channels
1
Conditioner Output Signal Type
Voltage
Conditioner Input Signal Type
Voltage
Conditioner Connection Type
Push-In Connection
Conditioner Output Signal Range
0 Ma - 5 Ma
Conditioner Output Signal Range
0 Ma - 10 Ma
Conditioner Output Signal Range
1 Ma - 5 Ma
Conditioner Output Signal Range
2 Ma - 10 Ma
Conditioner Output Signal Range
-5 Ma - 5 Ma
Conditioner Output Signal Range
-10 Ma - 10 Ma
Conditioner Output Signal Range
-20 Ma - 20 Ma
Conditioner Output Signal Range
0 Volt - 10 Volt
Conditioner Output Signal Range
-10 Volt - 10 Volt
Conditioner Output Signal Range
0 Volt - 5 Volt
Conditioner Output Signal Range
1 Volt - 5 Volt
Conditioner Output Signal Range
2 Volt - 10 Volt
Conditioner Output Signal Range
-5 Volt - 5 Volt
Conditioner Output Signal Range
0 Volt - 2.5 Volt
Conditioner Output Signal Range
0.5 Volt - 2.5 Volt
Conditioner Output Signal Range
-2.5 Volt - 2.5 Volt
Features
Analog signal conditioner for isolating, filtering, amplifying, and converting standard analog signals
Installation in zone 2 permitted
Up to SIL 2 in accordance with EN 61508
Over 1600 signal conversions can be set via DIP switches on the front
Plug-in screw or spring-cage connection technology (Push-in technology)
Active or passive output
Configurable input and output signals, including bipolar current and voltage signals
Status indicator for supply voltage
Wide-range power supply of 19.2 ... 253 V AC/DC
3-way electrical isolation
Downloads
Phoenix 2811569 Application Note English.pdfPhoenix 2811569 CAD data International.dxfPhoenix 2811569 CAD data International.pdfPhoenix 2811569 CAD data International.stpPhoenix 2811569 Certification English.pdfPhoenix 2811569 Certification International.pdfPhoenix 2811569 Data Sheet English.pdfPhoenix 2811569 Manual English.pdfPhoenix 2811569 Manufacturers declaration English.pdfPhoenix 2811569 Manufacturers declaration International-2.pdfPhoenix 2811569 Manufacturers declaration International.pdfPhoenix 2811569 Package Slip International.pdfPhoenix 2811569 Software International.xlsPhoenix 2811569 Tender Text English.zip
