VAL-MS-T1/T2 48/12.5 ST Phoenix Contact 2801242 Replacement plug Type 1/2 surge protection plug
VAL-MS-T1/T2 48/12.5 ST Phoenix 2801242 Replacement plug 60 VAC ±10 % pluggable Type 1/2 surge protection plug Surge Protection
Normally In Stock! Order now!
Condition: New
Usually ships Same Day or Next Day (MUST BUY IN PACKS OF 10)
Price: $197.50
Sale Price:
$164.32
L-N replacement plug for VAL-MS-T1/T2 48/12.5 plug-in lighting/surge arrester.
| Specifications | |
| Fault Warning | Optical |
| Arrester Class according to IEC | I - II |
| Arrester Class according to IEC | T1 - T2 |
| Manufacturer | Phoenix Contact |
| Connection Method | Screw connection |
| Surge Protector Type | Replacement plug |
| Maximum Continous Voltage | 100 Volt |
| Nominal Discharge Current | 12.5 kA |
| Surge Protector Line Voltage | 60 Volt ±10 % |
- Surge protection for (-) 48 V DC in lightning protection level III and IV due to discharge capacity of 12.5 kA per position
- Rapid installation with bridges, thanks to industry-standard overall width of 1 HP
- Easy testing and insulation measurement, thanks to pluggable protection modules
- Quality proven millions of times over in the widest range of applications
- Vibration-resistant latching ensures the plug remains firmly in place
