Lutze 722754 DRAN60-24A Power Supply 2.5A, 24V, 60W One Phase
Normally In Stock
Code: 418823
Lutze 722754 DRAN60-24A - Delta Series - 60 Watt - Input: 85 - 264 VAC, 90 - 375 VDC - Output: 24 VDC - One Phase - 2.5 Amp - 47 Hz-63 Hz - Plastic - IP20 - Screw Connections - AWG 26-12 - DIN Rail Mount
Condition: New
Usually ships Same Day or Next DayMUST ORDER A MINIMUM OF $100 FROM LUTZE FOR PRODUCT TO SHIP
*NON-CANCELLABLE, NON-RETURNABLE*
$79.81
Sale Price
$66.51
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Lutze 722754 DRAN60-24A - The standard Delta series offers an economical yet highly dependable solution, making it a go-to choice for various applications. With an efficiency rate exceeding 92% and low heat dissipation, it not only saves on energy costs but also ensures long-lasting performance. This series provides a wide input voltage range and a versatile output range spanning from 0.75 amps to 20 amps, catering to a range of needs. Its short circuit protection, parallel, and redundant features ensure safety and operational stability. The availability of spring, screw, and pluggable screw terminals enhances flexibility. Moreover, the series boasts a high Mean Time Between Failures (MTBF), is RoHs compliant, UL 508 Listed, and offers NEC Class 2 and multiple Class 1 Div.2 units, underscoring its comprehensive reliability and adherence to industry standards. - 1.6" x 3.5" x 4.5" (HxWxD)
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Voltage Output
24 VDC
Power Supply Watts (Nominal Power)
60 Watt
Power Supply Amperage Output
2.5 Amp
Component
Power Supply
Manufacturer
Lutze
Power Supply Voltage Input
85 - 264 VAC
Line
Delta Series
Power Supply Voltage Input
90 - 375 VDC
Power Supply Connection Type
Screw Connections
