Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Downloads
Schneider Electric BDA36020 PowerPact B Circuit Breaker, 20A, 3P, 600Y/347V AC, 14kA at 600Y/347 UL, I-Line
Schneider BDA36020 Circuit breaker 20 A 3P 25 kA 208Y/120 V AC 50/60 Hz UL 489, 25 kA 240 V AC 50/60 Hz UL 489, 18 kA 480/277 V AC 50/60 Hz UL 489, 18 kA 480 V AC 50/60 Hz UL 489, 14 kA 600Y/347 V AC 50/60 Hz UL 489, 10 kA 250 V DC UL 489 ABC 80 % I-Line Distribution BD 020 UL, I
Normally In Stock! Order now!
Condition: New
CALL FOR LEAD TIME
Price: $1518.00
Sale Price:
$738.72
Schneider BDA36020 Circuit breaker 20 A 3P 25 kA 208Y/120 V AC 50/60 Hz UL 489, 25 kA 240 V AC 50/60 Hz UL 489, 18 kA 480/277 V AC 50/60 Hz UL 489, 18 kA 480 V AC 50/60 Hz UL 489, 14 kA 600Y/347 V AC 50/60 Hz UL 489, 10 kA 250 V DC UL 489 ABC 80 % I-Line Distribution BD 020 UL, I
| Specifications | |
| Interrupt Code (Molded Case Breaker) | D Interrupt Rating |
| Amperage (Molded Case Breaker) | 20 Amp |
| Poles (Molded Case Breaker) | Three Pole |
| Frame Type (Molded Case Breaker) | B Frame |
| UL Listing (Molded Case Breaker) | UL 489 |
| Maximum Voltage (Molded Case Breaker) | 525 VAC |
| Mounting (Molded Case Breaker) | I-Line |
| Manufacturer | Schneider Electric |
| Manufacturer | Square D |
| Component | Molded Case Circuit Breaker |
| Interrupt Rating (Molded Case Breaker) | 18 kA 480 Volt |
| Interrupt Rating (Molded Case Breaker) | 10 kA 250 Volt |
| Interrupt Rating (Molded Case Breaker) | 25 kA 240 Volt |
| Interrupt Rating (Molded Case Breaker) | 25 kA 208Y/120 Volt |
| Interrupt Rating (Molded Case Breaker) | 18 kA 480/277 Volt |
| Interrupt Rating (Molded Case Breaker) | 14 kA 600Y/347 Volt |
