Phoenix Contact 2800036 Surge protection device S-PT-4-EX-24DC
Normally In Stock
Code: 10532
S-PT-4-EX-24DC Phoenix Contact Transient Surge Suppressor S-PT-4-EX-24DC Two-level surge protection for three or four signals of floating signal circuits in screw-on module with IP67 degree of protection.
Condition: New
Usually ships Same Day or Next Day$299.15
Sale Price
$249.29
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 2800036 The screw-on module features two-stage surge protection for three or four floating signal circuits, boasting an IP67 degree of protection for its sensor heads. The M20 x 1.5 connection method is utilized. Compliance testing has been conducted in Ex areas conforming to Ex d, Ex tD, Ex ia IIC/Ex iaD standards. This module is well-suited for integration into the FISCO fieldbus system and is also compatible with HART technology. Additionally, it can be employed in safety-related circuits, capable of supporting SIL 3 levels of integrity.
Specifications
Max Discharge Capacity
80 A
Fault Warning
Optical
Fault Warning
Remote Indicator Contact
Arrester Class according to IEC
II
Arrester Class according to IEC
T2
Manufacturer
Phoenix Contact
Connection Method
Screw Connection
Surge Protector Line Voltage
24 Volt
Maximum Continous Voltage
260 Volt
Surge Protector Type
Surge Arrester
Nominal Discharge Current
20 Ka
Component
Surge Protection Device
Features
Easiest field mounting with standardized thread
Versatile in use with universal protective circuit
Use under extreme ambient conditions with robust design
Downloads
Phoenix 2800036 CAD Drawing.zipPhoenix 2800036 Certification English.pdfPhoenix 2800036 Certification International.pdfPhoenix 2800036 Flyer English.pdfPhoenix 2800036 Manufacturers declaration International.pdfPhoenix 2800036 Package Slip International.pdfPhoenix 2800036 Software International.zipPhoenix 2800036 Spec Sheet.pdfPhoenix 2800036 Surge Protection English.pdfPhoenix 2800036 Table English.pdfPhoenix 2800036 Tender Text English.zipPhoenix 2800036 User Manual.pdf
