Images are for illustration only and may not reflect the actual product. Refer to the description or specs.
Phoenix Contact 2320018 DC/DC converter MINI-PS- 12- 24DC/ 5-15DC/2
Normally In Stock
Code: 817
MINI-PS- 12- 24DC/ 5-15DC/2 Phoenix Contact MINI-PS- 12- 24DC/5-15DC/2. DC-DC converter(Class 1 Div 2) 2A with 10-32Vdc input and 12 VDC output. Temperature range of -13 F to 158 F. Din rail mount. (3.9"H x .89"W x 4.21"D).
Condition: New
Usually ships within 7-14 days. Call for ship time.$327.77
Sale Price
$273.14
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 2320018 When designing or implementing new systems, consider incorporating the 1066704 Primary-switched MINI DC/DC converter that is specifically designed for DIN rail mounting. This compact converter can handle a wide range of input voltages from 12V DC to 24V DC and provide output voltages between 5V DC and 15V DC at up to 2A of current, making it an efficient and versatile component for various applications.
Specifications
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Voltage Output
12 VDC
Power Supply Housing
Enclosed
Power Supply Amperage Output
2 Amp
Manufacturer
Phoenix Contact
Line
MINI
Power Supply Amperage Output Range
0-5 Amp
Power Supply Voltage Input Range
10 VDC - 32 VDC
Component
DC-DC
Features
Support conversion to various voltage levels
Constant voltage: output voltage regenerated even at the end of long cables
Electrical isolation: for setting up independent supply systems
Downloads
Phoenix 2320018 CAD data International.dxfPhoenix 2320018 CAD data International.pdfPhoenix 2320018 CAD data International.stpPhoenix 2320018 CAD Drawing.dxfPhoenix 2320018 Data Sheet English.pdfPhoenix 2320018 Manufacturers declaration English.pdfPhoenix 2320018 Manufacturers declaration International-2.pdfPhoenix 2320018 Manufacturers declaration International.pdfPhoenix 2320018 Package Slip International.pdfPhoenix 2320018 Product Information English.pdfPhoenix 2320018 Spec Sheet.pdfPhoenix 2320018 Tender Text English.zipPhoenix 2320018 User Manual.pdfPhoenix 2320018 Various English.pdf
