Ilsco CPM-400 Pigtail Adaptor - Copper, 400 MCM, Stranded, 600 V, Silver
Normally In Stock
Code: 588402
Ilsco CPM-400 - Copper Compression Pigtail Adaptor, Conductor Size 400, Tin Plated, UL, CSA
Condition: New
CALL FOR LEAD TIME$125.84
Sale Price
$96.80
NO MOQ/PACK QUANTITY. QTY 1 = QTY 1
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Ilsco CPM-400 - The Copper Compression Pigtail Adaptor is a UL and CSA listed connector with a conductor size of 400 kcmil. Made of copper with tin plating, it is dual-rated and suitable for 600V applications. Supplied with an insulating cover, it features a compression connection and DE-OX® material. Conductor types include stranded aluminum. Can handle temperatures up to 90°C.
Specifications include:
- Conductor Size: 400 kcmil
- Material: Copper
- Connector Finish: Tin
- Dual Rated: Yes
- Temperature Rating: 90°C
- Voltage Rating: 600 V
- Contains DE-OX®: Yes
Specifications
Color
Silver
Manufacturer
Ilsco
Terminal for Wire Gauge
400 MCM
Material
Copper
Maximum Operating Temperature (Fahrenheit)
194 °F
Maximum Operating Temperature (Celsius)
90 °C
Connector Finish
Tin
Voltage Rating
600 V
Number of Connectors
1
Component
Pigtail Adaptor
Features
Barrel manufactured from high strength aluminum alloy
Pigtail manufactured from high conductivity copper
Chamfered barrel
UL Listed and CSA Certified for 600 volts, 90˚ C
Clearly marked with wire size and die index for ILSCO tools, proper number and location of crimps
Prefilled with DE-OX
Color coded end caps inserted in barrel
Supplied with insulating cover
Rated for full ampacity of incoming conductor
