Littelfuse PLM9805 Voltage Monitoring - 400-480 Volt, Double Throw, Single Pole
Normally In Stock
Code: 565382
Littelfuse PLM9805 - PLM Series – Voltage Monitor Series - 400-480 Volt - Plug-in socket - 10 A resistive @ 240 VAC 277 VAC max; 1/2 hp @ 240 VAC; 1/4 hp @ 120 VAC
Condition: New
Usually ships Same Day or Next Day$211.79
Sale Price
$176.49
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Littelfuse PLM9805 is an octal 8-pin plug-in relay with a load rating of 10 A resistive @ 240 V and 277 V max. It offers surge protection and automatic reset time, utilizing voltage detection for trip and reset. With a power consumption ≤3 W, it operates on 3-phase delta or WYE input types with no connection to neutral. The input phase sequence is A, B, C, and it has a trip delay range of 5 s fixed. It provides undervoltage trip voltage of 88-92% of the adjusted line voltage and has a trip delay tolerance of ±15%.
Specifications
Relay Throws
Double Throw
Relay Poles
Single Pole
Component
Voltage Monitoring Relay
Manufacturer
Littelfuse
Relay Mounting
Plug-In Socket
Coil Voltage Rating
400-480 Volt
Features
Quick octal 8-pin mounting
Proprietary microcontroller-based circuitry
LED diagnostics
Isolated, 10 A, SPDT output contacts
Adjustable, nominal voltage set point
Simple 3-wire connection for delta or wye systems
ASME A17.1 Rule 210.6
NEMA MG1 14:30, 14:35
IEEE C62.41-1991 Level B
