Phoenix Contact 2903160 Power supply TRIO-PS-2G/1AC/48DC/10
Normally In Stock
Code: 36903
TRIO-PS-2G/1AC/48DC/10 Phoenix Contact TRIO-PS-2G/1AC/48DC/10. 48 VDC output 10 Amp Power Supply and 85 Vac-264 Vac input voltage. Temperature range of -13 F to 158 F. Din rail mount Push-In Connection. (5.12"H x 2.67"W x 6"D).
Condition: New
Usually ships within 7-14 days. Call for ship time.$429.44
Sale Price
$357.87
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Phoenix Contact 2903160 A primary-switched Trio Power power supply features a convenient push-in connection for easy DIN rail installation, accepts a single-phase input and provides an output of 48V DC at up to 10A.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Watts
480 Watt
Power Supply Voltage Output
48 VDC
Power Supply Housing
Enclosed
Power Supply Amperage Output
10 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
TRIO
Power Supply Amperage Output Range
6-10 Amp
Power Supply Voltage Input Range
85 VAC - 264 VAC
Features
Electrically robust, thanks to high electric strength
Increase system availability, thanks to dynamic boost with 150 % of the nominal current for 5 seconds
Maximum flexibility due to the wide temperature range from -25°C to +70°C and device startup at -40°C
Save time and costs, thanks to the Push-in connection and narrow design
Mechanically robust, thanks to high vibration and shock resistance
Downloads
Phoenix 2903160 CAD data International.dxfPhoenix 2903160 CAD data International.pdfPhoenix 2903160 CAD data International.stpPhoenix 2903160 Data Sheet English.pdfPhoenix 2903160 Manufacturers declaration English.pdfPhoenix 2903160 Manufacturers declaration International-2.pdfPhoenix 2903160 Manufacturers declaration International.pdfPhoenix 2903160 Package Slip International.pdfPhoenix 2903160 Tender Text English.zipPhoenix 2903160 Various English.pdfPhoenix 2903160 Various English.wmv
