Phoenix Contact 2904611 Power supply unit QUINT4-PS/1AC/48DC/10
Normally In Stock
Code: 36902
QUINT4-PS/1AC/48DC/10 Phoenix Contact 2904611 Power Supply 48V 10A QUINT
Condition: New
Usually ships within 7-14 days. Call for ship time.$568.74
Sale Price
$473.95
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2904611 A primary-switched quint power supply is available for installation on DIN rails, allowing users to select their desired output curve and featuring Selective Fuse Breaking technology. The device accepts a single-phase input and delivers up to 480V DC at a maximum current rating of 10 amps.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Watts
480 Watt
Power Supply Voltage Output
48 VDC
Power Supply Housing
Enclosed
Power Supply Amperage Output
10 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Amperage Output Range
6-10 Amp
Power Supply Voltage Input Range
100 VAC - 240 VAC
Features
High degree of immunity, thanks to integrated gas-filled surge arrester and mains failure bridging time of more than 20 milliseconds
Signaling thresholds and characteristic curves that can be adjusted via NFC maximize system availability
Power reserve for easy system extension thanks to static boost with sustained power of up to 125% and ability to start difficult loads thanks to dynamic boost with up to 200% for 5 seconds
Preventive function monitoring indicates critical operating states before errors occur
Robust design thanks to metal housing and wide temperature range from -40°C to +70°C
Worldwide use thanks to the wide range input and international approval package
Downloads
Phoenix 2904611 CAD data International.dxfPhoenix 2904611 CAD data International.pdfPhoenix 2904611 CAD data International.stpPhoenix 2904611 Data Sheet English.pdfPhoenix 2904611 Manufacturers declaration English.pdfPhoenix 2904611 Manufacturers declaration International-2.pdfPhoenix 2904611 Manufacturers declaration International.pdfPhoenix 2904611 Package Slip International.pdfPhoenix 2904611 Software International.zipPhoenix 2904611 Tender Text English.zipPhoenix 2904611 Various English.pdfPhoenix 2904611 Various English.wmv
