Phoenix Contact 2904610 Power supply unit QUINT4-PS/1AC/48DC/5
Normally In Stock
Code: 36901
QUINT4-PS/1AC/48DC/5 Phoenix Contact 2904610 Power Supply 48V 5A QUINT
Condition: New
Usually ships within 7-14 days. Call for ship time.$463.98
Sale Price
$386.65
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2904610 A quint power primary-switched power supply is available for installation on a DIN rail, allowing users to select from various output characteristic curves. This unit incorporates SFB technology, enabling selective fuse breaking, and is powered by a single-phase input source with an output voltage of 48V DC and a maximum current rating of 5A.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Voltage Output
48 VDC
Power Supply Watts
240 Watt
Power Supply Housing
Enclosed
Power Supply Amperage Output
5 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Amperage Output Range
0-5 Amp
Power Supply Voltage Input Range
100 VAC - 240 VAC
Features
High degree of immunity, thanks to integrated gas-filled surge arrester and mains failure bridging time of more than 20 milliseconds
Signaling thresholds and characteristic curves that can be adjusted via NFC maximize system availability
Power reserve for easy system extension thanks to static boost with sustained power of up to 125% and ability to start difficult loads thanks to dynamic boost with up to 200% for 5 seconds
Preventive function monitoring indicates critical operating states before errors occur
Robust design thanks to metal housing and wide temperature range from -40°C to +70°C
Worldwide use thanks to the wide range input and international approval package
Downloads
Phoenix 2904610 CAD data International.dxfPhoenix 2904610 CAD data International.pdfPhoenix 2904610 CAD data International.stpPhoenix 2904610 Data Sheet English.pdfPhoenix 2904610 Manufacturers declaration English.pdfPhoenix 2904610 Manufacturers declaration International-2.pdfPhoenix 2904610 Manufacturers declaration International.pdfPhoenix 2904610 Package Slip International.pdfPhoenix 2904610 Software International.zipPhoenix 2904610 Tender Text English.zipPhoenix 2904610 Various English.pdfPhoenix 2904610 Various English.wmv
