Omega DMD-475 BRIDGE AMPLIFIER NOCE
Normally In Stock
Code: 790203
Omega DMD-475 BRIDGE AMPLIFIER NOCE
Condition: New
Usually ships Same Day or Next Day$1235.54
Sale Price
$1029.62
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Isolated Signal Conditioner with Transducer Power up to 120 mA for Strain Gages, Load Cells & Transducers, 5 mV to 50 mV I/P, 5 mA O/P, FGPR, for Bridge-type Inputs, DMD-470 Series, Each
Specifications
Component
Signal Conditioner
Conditioner Output Signal Type
Voltage
Conditioner Input Signal Type
Voltage
Manufacturer
Omega Engineering
Conditioner Output Signal Range
0-10 Vdc
Features
700 V I/O Isolation
1100 V Line Isolation
Power for Four 350 Ohm Load Cells, Fixed 10 V or Variable 5 to 10 Vdc
Adjustable Gain and Offset
Accuracy± 0.15 %
Capacitance60 pF
Compliance Voltage20 Vdc
Current Output5 mA
Excitation Voltage NoteVoltage Range: 5 to 10 Vdc
Current Output: 120 mA max
Line and Load Regulation: 0.02% max
Output Noise: 1 mVrms max (120 Hz)
Temp Coefficient: 60 ppm @ 10V, 100 ppm max
Gain Range200 to 2000
Height73 mm
Input Range5 to 50 mV
Input Resistance1000 MΩ
Input TypeVoltage
IsolationAC Line: 1100 Vrms, 60 pF, Input to Output: 700 Vdc and 60 pF
Length96 mm
Linearity± 0.005%
Long Term StabilityTemperature: 0.005%/°C
Operating Temperature, Max55 °C
Operating Temperature, Min-25 °C
Response Time35 ms
Response Time Note10 to 90% = 35 ms
Storage Temperature, Max85 °C
Storage Temperature, Min-25 °C
Supply Power120 Vac
Supply Power Note115 Vac ± 10 Vac standard or 220 Vac ± 10% 50/60 Hz optional
Supply Power TypeAC
Tare Adjustment-3 to 25 mV
Weight510 g
Width51 mm
Zero Setting Adjustable Range0 to 2 V
