6 Channel PID Loop

Universal TC, RTD and Process Inputs Firmware Selectable

User Programmable Alarms Individually Settable per Channel

Adjustable Scan Time: 400ms Scan Rate per Channel

A/D Conversion24-bit Sigma Delta

Accuracy± 1 mV

Accuracy Detail± 1 mV

Additional Features 12 Alarm Outputs

ApprovalsECCN: EAR99 Safety: 2014/35/EU EMC: 2014/30/EU RoHS: 2011/65/EU UL File No: E209855 UL/cUL Listed

Channel Display Time1 to 99 sec

Cutout Dimensions92 × 92 mm

Data InterfaceRS232

Data Interface NoteSelectable RS232 / RS485 Modbus RTU

Depth Behind Panel140 mm

Diameter135 mm

Display Size15 mm (0.60 in)

Display TypeDual 3.5 Digit LED

Display Type Note3.5 Digit Dual Display

Electrical Output4 to 20 mA, 0 to 1 Vdc

Enclosure RatingsNEMA Type 1

Form factor1/4 DIN

Frequency50/60 Hz

Input TypeThermocouple, RTD, Voltage, Current

Input Type NoteTC: J, K, T, E, R, S, B, C, N RTD: 2 wire PT100, 0.00385 CU10, 0.00427 NI120, 0.00672

Length95 mm

Measurement TypeCurrent, Temperature, Voltage

Measuring RangeProcess Voltage: 0 to 1000 mV Process Current: 0 to 24.00 mA Thermocouple Type J: -150 to 0°C and 0 to 1200°C Type K: -150 to 0°C and 0 to -1372°C Type T: -150 to 0°C and 0 to 400°C Type E: -150 to 0°C and 0 to 1000°C Type R: -50 to 0°C and 0 to 1788°C Type S: -50 to 0°C and 0 to 1768°C Type B: 150 to 700°C and 700 to 1820°C Type C: 0 to 2320°C Type N: -150 to 0°C and 0 to 1300°C RTD (2 wire) Pt, 0.00385, 100 Ω: -200 to 850°C Cu, 0.00427, 10 Ω: -200 to 260°C Ni, 0.00672, 120 Ω: -80 to 260°C

Number of Inputs6

Number of Outputs6

Operating Temperature, Max70 °C

Operating Temperature, Min-20 °C

Output Detail6 Common Drain DC Pulse Outputs Switches up to 36Vdc and 1A, 5Vdc @25mA per channel

Power Consumption3 W

Ramp and SoakMultiple Ramp & Soak

Resolution1°, 1 mV, 0.01 mA

Scan Rate400 ms

Storage Temperature, Max85 °C

Storage Temperature, Min-40 °C

Supply Voltage120/240 Vac

Weight725 g

Width95 mm
