Phoenix Contact 2904603 Power supply QUINT4-PS/1AC/24DC/40
Normally In Stock
Code: 68242
QUINT4-PS/1AC/24DC/40 Phoenix 2904603 Power supply 100 VAC - 240 VAC -15 % - +10 % 40 Amp 100 VAC - 240 VAC -15 % - +10 % Power Supplies and UPS
Condition: New
Usually ships Same Day or Next Day$686.04
Sale Price
$571.70
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2904603 The 24V DC power supply features a primary-switched design that offers flexibility in choosing the desired output current curve, along with selective fuse breaking technology for added safety. The device also includes an NFC interface and can be powered by a single-phase input source.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Voltage Output
24 VDC
Power Supply Watts
960 Watt
Power Supply Housing
Enclosed
Power Supply Amperage Output
40 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Amperage Output Range
31-40 Amp
Power Supply Voltage Input Range
100 VAC - 240 VAC
Features
Available pre-configured: from a batch quantity of just 1
Most robust input side: high noise immunity, thanks to integrated gas-filled surge arrester (up to 6 kV) and ≥ 20 ms mains failure buffer time
Most comprehensive signaling: preventive function monitoring reports critical operating states before errors occur
Most powerful output side: easy system expansion, reliable heavy load startup and miniature circuit breaker tripping
Downloads
Phoenix 2904603 CAD data International.dxfPhoenix 2904603 CAD data International.pdfPhoenix 2904603 CAD data International.stpPhoenix 2904603 Data Sheet English.pdfPhoenix 2904603 Manufacturers declaration English.pdfPhoenix 2904603 Manufacturers declaration International.pdfPhoenix 2904603 Package Slip International.pdfPhoenix 2904603 Software International.zipPhoenix 2904603 Tender Text English.zipPhoenix 2904603 Various English.pdfPhoenix 2904603 Various English.wmv
