Phoenix Contact 2904617 Power supply QUINT4-PS/1AC/24DC/20/+
Normally In Stock
Code: 68237
QUINT4-PS/1AC/24DC/20/+ Phoenix 2904617 Power supply 100 VAC - 240 VAC -15 % - +10 % 20 Amp 100 VAC - 240 VAC -15 % - +10 % Power Supplies and UPS
Condition: New
Usually ships Same Day or Next Day$587.35
Sale Price
$489.46
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2904617 A QUINT POWER supply unit is available in a compact form for installation on DIN rail, offering adjustable output characteristic curves through SFB Technology. This technology enables selective fuse breaking and incorporates protective coating to enhance safety. Additionally, the device features an integrated decoupling MOSFET and accepts 1-phase input power, while delivering a stable output voltage of 24V DC at up to 20A.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Watts
480 Watt
Power Supply Voltage Output
24 VDC
Power Supply Housing
Enclosed
Power Supply Amperage Output
20 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Amperage Output Range
16-20 Amp
Power Supply Voltage Input Range
100 VAC - 240 VAC
Features
Available pre-configured: from a batch quantity of just 1
Most robust input side: high noise immunity, thanks to integrated gas-filled surge arrester (up to 6 kV) and ≥ 20 ms mains failure buffer time
Most comprehensive signaling: preventive function monitoring reports critical operating states before errors occur
Most powerful output side: easy system expansion, reliable heavy load startup and miniature circuit breaker tripping
Downloads
Phoenix 2904617 CAD data International.dxfPhoenix 2904617 CAD data International.pdfPhoenix 2904617 CAD data International.stpPhoenix 2904617 Data Sheet English.pdfPhoenix 2904617 Manufacturers declaration International-2.pdfPhoenix 2904617 Manufacturers declaration International.pdfPhoenix 2904617 Package Slip International.pdfPhoenix 2904617 Software International.zipPhoenix 2904617 Tender Text English.zipPhoenix 2904617 Various English.pdfPhoenix 2904617 Various English.wmv
