Phoenix Contact 2866802 Power supply QUINT-PS/3AC/24DC/40
Normally In Stock
Code: 670
Phoenix Contact QUINT-PS/3AC/24DC/40 24 VDC output 40 Amp Premium Power Supply(Class 1 Div 2) with 3-Phase input voltage 320-575 Vac or 450-800 Vdc . Din rail mount Screw Connection. Temperature range of -13 F to 158 F.
Condition: New
Usually ships Same Day or Next Day$1327.66
Sale Price
$1106.38
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Phoenix Contact 2866802 The QUINT POWER power supply unit features a primary-switched design and can be easily installed on a DIN rail with its screw connection. It also incorporates the SFB Technology for selective fuse breaking, allowing for added safety and protection against electrical faults. The unit accepts a 3-phase input and provides a stable output of 24V DC at a maximum current capacity of 40A.
Specifications
Power Supply Type
Switching
Power Supply Mounting
Din Rail Mount
Power Supply Number of Outputs
Single Output
Power Supply Voltage Output
24 VDC
Power Supply Watts
960 Watt
Power Supply Housing
Enclosed
Power Supply Amperage Output
40 Amp
Component
Power Supply
Manufacturer
Phoenix Contact
Line
QUINT
Power Supply Voltage Input Range
320 VAC - 575 VAC
Power Supply Amperage Output Range
31-40 Amp
Power Supply Voltage Input Range
450 - 800 VDC
Features
High level of system availability even in the event of permanent phase failure
Preventive function monitoring
Reliable starting of difficult loads
Downloads
Phoenix 2866802 CAD data International.dxfPhoenix 2866802 CAD data International.pdfPhoenix 2866802 CAD data International.stpPhoenix 2866802 CAD Drawing.dxfPhoenix 2866802 Data Sheet English.pdfPhoenix 2866802 Manufacturers declaration English.pdfPhoenix 2866802 Manufacturers declaration International-2.pdfPhoenix 2866802 Manufacturers declaration International-3.pdfPhoenix 2866802 Manufacturers declaration International.pdfPhoenix 2866802 Package Slip International.pdfPhoenix 2866802 Product Information English.pdfPhoenix 2866802 Spec Sheet.pdfPhoenix 2866802 Tender Text English.zipPhoenix 2866802 User Manual.pdfPhoenix 2866802 Various English.pdfPhoenix 2866802 Various English.wmv
