Ilsco IKB-500 Split Bolt - Copper, 500-400 MCM, Stranded, 35 kV, Copper
Normally In Stock
Code: 588945
Ilsco IKB-500 - Copper Two-Bolt Split Bolt, Main Conductor Range 500-400, Tap Range 500-10, UL
Condition: New
CALL FOR LEAD TIME$191.45
Sale Price
$147.27
NO MOQ/PACK QUANTITY. QTY 1 = QTY 1
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Related Products
Description
Ilsco IKB-500 - Copper Two-Bolt Split Bolt for primary run with a conductor range of 500-400 kcmil. UL listed with a 35 kV voltage rating. Ideal for mechanical connections, it features an external hex drive type. Suitable for 2 conductors with a main conductor range of 500 kcmil - 400 kcmil. Temperature rated at 90°C.
Specifications
Manufacturer
Ilsco
Material
Copper
Component
Split Bolt
Maximum Operating Temperature (Fahrenheit)
194 °F
Maximum Operating Temperature (Celsius)
90 °C
Color
Copper
Voltage Rating
35 Kv
Terminal for Wire Gauge
500-400 MCM
Number of Connectors
2
Features
Manufactured from high strength copper alloy
Two bolt design
Longer peened bolt
Suitable for use in circuits rated 35KV or less, proper high voltage spacing and insulation techniques must be used
For copper conductor only
Rated to 90˚ C
