Dwyer DPMX-1 Extra Large Digital Panel Meter
Normally In Stock
Code: 575491
Dwyer DPMX-1 - Extra large digital panel meter, blue LED segment display, with 90 to 250 VAC supply power.
Condition: New
Usually ships Same Day or Next Day$763.93
Sale Price
$636.61
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMX-1 is an extra-large digital panel meter with a temperature range of 14 to 122°F (-10 to 50°C). It has a high accuracy of ±(1% F.S. + 1 count) and can be powered with either 90 to 250 VAC @ 12 VA or 10.5 to 30 VAC/DC @ 6 VA, depending on the model. Mounting options include 180° gimbal with 30° stops or bezel mount. The 3-1/2 digit, 2.3" height, 7 segment LED display is easy to read. Input options include set voltage, adjustable voltage, and adjustable current. The sampling rate is 3 readings per second and the warm-up time is only 10 ms. It has a storage range of -40 to 167°F (-40 to 75°C).
Specifications
Component
Digital Panel Meter
(Instrument-Sensor) Measurement Accuracy
1%
Sub Component
Extra Large
(Instrument-Sensor) Temperature Range
14 - 122°F/-10 - 50°C
Manufacturer
Dwyer Instruments
Features
Large 10.6" (269.2 mm) x 4.2" (105.7 mm) backlit display
Protective metal casing with adjustable mounting bracket
