Dwyer DPMA-500 LCD Digital Process Meter
Normally In Stock
Code: 571625
Dwyer DPMA-500 - DPMA-500 VOLT CONT NO BKLITE
Condition: New
Usually ships Same Day or Next Day$225.50
Sale Price
$187.92
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMA-500 is an LCD Digital Process Meter with a temperature range of 32 to 122°F (0 to 50°C). It has an accuracy of ±(0.05% FS + 1 count) and adjustable zero and span adjustments (±1999 counts). It can be powered by a control loop or 12 VDC/24 VDC. Mounting options include snap-in panel mount or clamp. It has a 3-1/2 digit, 7-segment display and screw terminals for connection. The input ranges are 4-20 mA or 0-200 mVDC, 0-5 VDC, or 0-10 VDC. It has a conversion rate of 3 per second and a warm-up time of 10 minutes. The DPMA-500 displays engineering units such as °F, °C, %, and psi (or V, A, KW, PF for DPMA-500P). It has automatic polarity with a "-" displayed and a backlight power supply of 24 VDC @ 35 mA.
Specifications
Component
Digital Panel Meter
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
(Instrument-Sensor) Measurement Accuracy
0.05%
Manufacturer
Dwyer Instruments
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
