Dwyer DPMA-403 LCD Digital Process Meter
Normally In Stock
Code: 571622
Dwyer DPMA-403 - DPMA-403 4-20 MA BLUE #/BKLITE
Condition: New
Usually ships Same Day or Next Day$237.82
Sale Price
$198.18
Tariff Status
Tariff may apply if shipping to the United States. Tariff costs are calculated and will be displayed in the shopping cart.
Need a large quantity or a custom solution?
Add this product to your job, favorites list or request a quick quote for volume pricing and lead time information. Our team is ready to assist with any special requirements.
Description
Dwyer DPMA-403 is an LCD Digital Process Meter with a temperature range of 32 to 122°F (0 to 50°C). It has an accuracy of ±(0.05% FS + 1 count) and adjustable zero and span adjustments. The meter can be powered by control loop or 12V/24VDC. It features a 3-1/2 digit, 1" (25.4 mm) H display, screw terminals for easy connection, and various input options. The meter supports engineering units like °F, °C, %, psi, V, A, KW, PF with selectable decimal points. Conversion rate is 3 per second and warm-up time is 10 minutes. Backlight power supply is 24VDC @ 35mA.
Specifications
Component
Digital Panel Meter
Sub Component
LCD
(Instrument-Sensor) Temperature Range
32 - 122°F/0 - 50°C
(Instrument-Sensor) Measurement Accuracy
0.05%
Manufacturer
Dwyer Instruments
Features
Panel mount for quick installation
3-1/2 or 4-1/2 digit with 0.45˝ or 1˝ segments
Colored segments available in black, red, amber, green, or blue
Jumper selectable engineering units and decimal point positions
